Layer: bathymetry10mCoverage (ID: 0)

Name: bathymetry10mCoverage

Display Field:

Type: Raster Layer

Geometry Type: null

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>This data shows the depth of the seabed around Ireland between 0 and 200 metre depths. The data was collected between 2001 and 2021. </SPAN></P><P><SPAN>Bathymetry is the measurement of how deep is the sea. Bathymetry is the study of the shape and features of the seabed. The name comes from Greek words meaning "deep" and “measure". Bathymetry is collected on board boats working at sea and airplanes over land and coastline. The boats use special equipment called a multibeam echosounder. A multibeam echosounder is a type of sonar that is used to map the seabed. Sound waves are emitted in a fan shape beneath the boat. The amount of time it takes for the sound waves to bounce off the bottom of the sea and return to a receiver is used to determine water depth. </SPAN></P><P><SPAN>LiDAR (Light Detection and Ranging) is another way to map the seabed, using airplanes. Two laser light beams are emitted from a sensor on-board an airplane. The red beam reaches the water surface and bounces back; while the green beam penetrates the water hits the seabed and bounces back. The difference in time between the two beams returning allows the water depth to be calculated. LiDAR is only suitable for shallow waters (up to 30m depth). </SPAN></P><P><SPAN>The data are collected as points in XYZ format. X and Y coordinates and Z (depth). The boat travels up and down the water in a series of lines (trackline). An XYZ file is created for each line and contains thousands of points. The line files are merged together and converted into gridded data to create a Digital Terrain Model of the seabed. </SPAN></P><P><SPAN>Colours are also used to show depth ranges. Reds and browns show heights above sea-level. Yellows and greens are shallow waters up to 45m deep. Blues (up to 110m deep) and purple show deeper waters up to 200m deep. </SPAN></P><P><SPAN>This is a raster dataset. Raster data stores information in a cell-based manner and consists of a matrix of cells (or pixels) organised into rows and columns. The format of the raster is a grid. The grid cell size is 10m by 10m. This means that each cell (pixel) represents an area on the seabed of 10 metres squared. Each cell has a depth value which is the average depth of all the points located within that cell. </SPAN></P><P><SPAN>This data shows areas that have been surveyed. There are plans to fill in the missing areas between 2020 and 2026. The deeper offshore waters were mapped as part of the Irish National Seabed Survey (INSS) between 1999 and 2005. INtegrated Mapping FOr the Sustainable Development of Ireland's MArine Resource (INFOMAR) is mapping the inshore areas. (2006 - 2026).</SPAN></P></DIV></DIV></DIV>

Copyright Text: Contains Irish Public Sector Data (Geological Survey Ireland & Marine Institute) licensed under a Creative Commons Attribution 4.0 International (CC BY 4.0) licence

Default Visibility: true

MaxRecordCount: 0

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: false

Supports Statistics: false

Has Labels: false

Can Modify Layer: false

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

Drawing Info:

N/A Advanced Query Capabilities:

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeNone

Type ID Field: null

Fields: None

Supported Operations: Query Query Attachments Query Analytic Generate Renderer Return Updates

Iteminfo Thumbnail Metadata
